Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 358

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 358
s appropriate recess in thesocket in the foot, so as to prevent vibrationin a horizontal plane, while leaving thejoint free for motion in vertical planes, asdescribed. The elastic straps, a, b (3), areproportioned as to length and strength, and afford a means of attach-ing the suspensory yoke (4),… … 903 a. ONE-MANCROSSCUT SAW. The illustrationshows how to rig up alarge crosscut saw tocut large logs withoutthe aid of another per-son. The opposite end of the saw is kept from digging too deeplyinto the wood by a rope run over two pulleys on posts and aweight tied to its end. The weight should be…

Mechanical movements
