Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 364

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 364
909. THE CAM-PYLO GRAPH. A machine for tracingcomplex geometricalcurves. The smallcrank on the bottomplatform rotates theplate containing a mul-tiple series of gears,which mesh with pin-ions on four radialarms and transfer theirmotion through foursmall but similar gear plates to verticalspindles…

Mechanical movements
