Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 369
center ofoscillation, showing thatthe weight P balances theweight W at any positionon the cross arm H, I, onthe vertical arm B, E,when pivoted to thedouble-scale beam A, B,and D, E, in which theresolution of forces ismade apparent in a prac-tical form so often over-looked by the inventorsof… … PERPETUAL MOTION. 365 Desaguliers Demonstration.—A, C, B, E, K, D is a balance in the formof a parallelogram passing through a slit in the upright piece, N, O, stand-ing on the pedestal, M, so as to be movable upon the center pins C and K.To the upright pieces, A, D and B, E, of this balance, are…
Mechanical movements
