Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 372

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 372
an aright line from the center of the cir-cumference of the wheel. The levers are furnished at their outer ex-tremities with a bucket or receiver, the bottom of which is sufficientlybroad to retain the ball C. The balls remain in the buckets till thebuckets come into the position of the lever, D,…

Mechanical movements
