are jointed, as shown,and to each of them is fixed aframe in which a weight, D,moves. When any spoke is in ahorizontal position, the weight,D, in it falls down, and pullsthe weighted arm, A, of the thenvertical spoke straight out, bymeans of a cord, C, going overthe pulley, B, to the weight D.But…
