Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 387

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 387
the bellows far-thest from the center must open,and those nearest must close. A liquidhaving been poured into each radiusin sufficient quantity to fill its channeland one of the bellows, it is evidentthat on the side, C, such liquor will be at the extremity, that is to say. inthe bellows that are… … PERPETUAL MOTION. 3^3 955. PERPETUAL MOTION. Chain-pump type. A series ofballs placed parallel to each other are hinged or linked together in asimilar manner as the buckets of a chain pump;this chain of floats is passed over two sets of pulleysor disks fixed to two horizontal shafts, the oneplaced…

Mechanical movements
