Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 43

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 43
red ink that has been diluted withabout one-quarter of its volume of glycerin. The glycerin preventsthe ink from drying too rapidly. To receive the atmospheric fluctuations a suitable ruled paper isfastened by means of small brass clamps, K K, to the board, H H,which is hung by rollers to the thick… … MEASUREMENT OF POWER, SPRINGS. 39 45. REGISTERING AIR THERMOMETER. A glass tubebent into a circle with an air bulb at the top nicely balanced by coun-terweights on a knifeedge. Part of the tube, asshown by the heavy blackline, is filled with mercury.The expansion and con-traction of the air in…

Mechanical movements
