Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 46

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 46
gg, which is fastened by means of two small clamps to the board thatis carried sideways by the clock, h. Over the metallic thermometerbar above the roof is a glass shade, i, protecting it from the weather,or covered with a louver box when used for recording temperature only.On the register paper, g… … 53. CENTRIFUGAL SPEED INDICATOR. Gravity of acolored fluid in the central and outer tubes is Varied by the centrif-ugal force of revolution for a constant in-dicator. The machine consists of three tubes, a, b,I?1, which connect freely with one another,and are mounted vertically between…

Mechanical movements
