Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 55

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 55
t of pull is indicatedin pounds upon the gage just before the vehicle driving-wheels slip orthe engine stops. This dynamometer may also be used to indicatethe tension in tow line or draft gear. As will be apparent, an instru-ment of this nature may be used very easily in making comparativetests… … 72B. CEMEXT-TESTIXG MACHINE. The illustration showsthe Riehle United States standard 1,000-pound automatic cementtester. The machine is made entirely of metal. The beam is broughtto a balance by pouring shot into the cone-shaped bucket on the left of the machine, thus counter-balancing the weight…

Mechanical movements
