Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 62

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 62
a-sons ; I is a safety valve ;K is a pressure gauge, andL is a water gauge. Diameter of top 9 feet;45 square feet of silveredglass surface. Boiler of blackened copper 31 inches high, 11 inchesdiameter. Thin glass cover 2 inches larger than boiler. Pressure generated 7 5 lbs. per square inch ; 11… … SS^i-Sfcasfc^^ ;8 GENERATION OF POWER. STEAM.
