Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 64

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 64
A water tube grate with tubes between the furnace head and a cross-head between the doors of the upper and lower furnace for obtaining aperfect circulation in the grate. 95. Longitudinal section of furnace. 6o GENERATION OF POWER, STEAM. 96. ANNULAR STEAM BLOW-ER. For boiler and other furnaces.…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
