Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 65

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 65
eam. The air and steama are thoroughly mixed in the shell of the blow-er before the blast is delivered into the ashpit. It makes very little noise in operation. 99. Section, showing ring and jets. 100. COAL DUST FEEDING APPARA-TUS. A revolving steel brush carries the coaldust into the furnace with… … GENERATION OF POWER, STEAM. 61 101. COAL DUST BURNER. The vertical tube, a, for intro-ducing the air serves as a pivot to the system, which comprises : i, themovable jacket, b, to which are bolted the primary air conduit, c, andthe secondary air conduit, d; 2, the hopper, e, supported by the…
