Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 69

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 69
116. LIQUID FUEL BURNER. Cup grate type, operated by natural draught of thechimney. The heat of the furnace heats theinner edge of the cups or troughs, vaporizes theoil, which mixes with the air in draught. Theoil is fed to the upper trough and overflows tothe next trough, and so on for as many…

Mechanical movements
