Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 82

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 82
ENGINE. Showing Corlissvalves on low-pressure cylin-der, direct connected wristplates, one for each cylinderto operate the steam valveswhile the exhaust valves areall connected by link rods,which are in turn directlyconnected to the eccentricrod. Valve gear of both cyl-inders have trip hooks… … 152. CORLISS EN-GINE. C. & G. Coopertype with double wrist plate.The governor controls theaction of the steam valvesby adjustable trip hooks anddashpots.
