Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 88

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 88
t. The small cylinders in each endof the main cylinder have each alive steam port and an exhaust, andwithin them pistons work freely asindependent valves, each having astem normally projecting within the main cylinder. These valves areoperated in one direction by the main piston coming in contact… … 171. TYPES OF SLIDE VALVES. Slide valve of the Chandler& Taylor tandem compound engine. The valve is of the gridiron type, and is double-ported for both steam andexhaust, making it possible to admitlarge amounts of steam into each end ofthe cylinder quickly and with a veryshort valve travel.…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
