Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 97

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 97
92 STEAM POWER APPLIANCES. … 199. FLEXIBLE CRANK for marine shafting. The crank pin isfixed in one side and swiveled in theother side of a double crank, asshown, giving flexibility to a line ofshafting in marine engines. 200. FLEXIBLE COUPLINGS for marine shafting. A ball bear-ing between the sectional ends of a line of…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
