PLATE 5* Make three views—top, front, and right side—ofone of the pieces shown in perspective on pages 62to 64. The problem will occupy the entire sheet.Leave from V to W between the views, and locatethe drawing on the sheet with equal spaces at theright and the left, also at the top and the… … Plate 5 OBJECTS WITH OBLIQUE SURFACES 63
Mechanical drawing
