Fig. 308. Measuring the Diameter of a Cylinder with the Caliper measured with the steel scale, as shown in Fig. 307. Note thatone point of the caliper rests against the end of the scale so thatthe operators attention may be given entirely to reading thescale division at the other point. … Fig. 309. Measuring the Diameter of a Hole with the Caliper The outside caliper is used in obtaining dimensions of curvedsurfaces. See Fig. 308. It is adjusted and the measurementtaken from the scale as previously described. The inside caliper is used in measuring the diameters of holesand the…
