Center a Perspective Sketch on a Sheet,page 40. 42 MECHANICAL DRAWING 2. Complete the enclosing solid as in Plate 2, page 35, takingcare to secure the necessary convergence. As it is the aim thatthe student should learn to make perspective sketches entirelyfreehand he should now draw as many as… … Fig. 34. Lettering Plate inch and H F and E I to represent one-half inch. From H and Idraw lines converging with A N and D M to the right. Lay offA K to represent two inches and draw a line from K convergingwith A D. This line meets the lines from H and I in L and 0respectively. Connect E 0 and F…
