Pig. 62, Bird House (Dimensioned Perspective) essential difference? (d) What movements are made to producethe line ? 10. (a) What is meant by constructive stage? (b) Finish-ing stage ? 11 In what way does a scale of levels assist in making aperspective of a rectangular object ? 12. (a) Where are… … Fig. 63. Book Eack (Dimensioned Perspective) 15. (a) What is a measure cube? (b) Why is it called ameasure cube ?
