being of wood, may be represented, if desired, asshown on page 61. Fig. 68. Front., top., and left side views of a flatiro?t. Fig. 69. A front view., a section on CD., and a horizontal section atAB through a horizontal spool. Draw the section on CD first. Fig. 70. Front and top views of a vertical… … Fig. 66.
