Mechanical drawing : a manual for teachers and students (1902)
Cross, Anson Kent · Boston : Ginn & Co. · leaf 26
cle C. Draw the diameter i—2^nd a radius j-^ per-pendicular to it. Bisect 2-3 in 5, and with 5 ascentre and radius ^-4, intersect 2-1 in 6. With4 as centre and radius 4-6 intersect the circle in7. Set off the distance 4-/ from y to 8, 8 to g,g to 10. Join 4-/, /-8, 8-g, g-io, and 10-4. Problem…
