Mechanical drawing : a manual for teachers and students (1902)
Cross, Anson Kent · Boston : Ginn & Co. · leaf 33
Problem 45. proximate ellipse. … To draw up07i given axes, AB and CD, an ap- With the centre, 6, of the ellipse ascentre and half the short axis, <5 C, asradius describe an arc C i. Draw CB andfrom C set off C2 equal to B i, or thedifference between half the short and halfthe long axis. Bisect B 2 and continuethe bisecting line…
Mechanical drawing
Internet Archive · Boston Public Library · Public Domain Mark 1.0. Free to use for anything.
