Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 102
Cellar Plan for Cottage House. Scale 1-8 in.=l ft. … \ST. F\_OOR Sca/Le. Fig. 122, the actual length of the sketchis 4% inches, but it would be entirelywrong to place that dimension on thedrawing. The dimension that should ap-pear is the dimension that the 4% inchesrepresents on the scale that is being used,that is, 18 feet. This point may not have…
Plumbing · Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
