Fig. 130. Scale 1-8 In.= l it. CHAPTER XXIV BEFORE leaving this part of oursubject, there is one system,the plumbing for a countryresidence, which it is desirableto take up. This work is different from city workin several respects, and we believe itwill be of benefit to consider such a sys-tem. For… … ..Floor P1A.TL F\O.V5\. in Figs. 131, 132 and 133, the second andfirst floor plans and cellar plan respect-ively. The cellar plan shows some differencefrom the same plan for city work, fromthe fact that on this plan, the locationsof well, cesspool, etc., is shown. In thesecond floor plan, we show…
