! Fie*. 30> Showing How Curve of Trap is Made Too Low Dowsio 28 MECHANICAL DRAWING FOR PLUMBERS … MECHANICAL DRAWING FOR PLUMBERS 29 the running trap of Fig. 30. The com-mon fault in drawing this fitting is tomake the curve of the trap too low down,that is, to give the trap- a much deeperseal than is it really has. Another faultshown in No. 2 as compared with No. 1,is the length of the straight…
