Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 69
this we now show inFig. 74. In showing an elevation of the three-flat apartment work, we brought out the To clearly demonstrate this point, weshow in Fig. 75 a floor plan of the samework that we showed in connection withthe work of the preceding article, the lay-out of the floor plan being… … Fi^.75.: point that it often occurs that a completeelevation of the plumbing work of any ex-tent cannot be shown to the best advan-tage by taking a view of all parts of thework from one direction, and that it isoften best, and indeed almost necessaryto a clear understanding of the drawing,to make…
Plumbing · Mechanical drawing
