Mechanical drawing self-taught: comprising instructions in the selection and preparation of drawing instruments, elementary instruction in practical mechanical drawing together with examples in simple geometry and elementary mechanism, including screw threads, gear wheels, mechanical motions, engines and boilers (1883)

Rose, Joshua · Philadelphia, H.C. Baird & Co.; London, S. Low, Marston, Searle & Rivington · leaf 161

An illustration from Mechanical drawing self-taught: comprising instructions in the selection and preparation of drawing instruments, elementary instruction in practical mechanical drawing together with examples in simple geometry and elementary mechanism, including screw threads, gear wheels, mechanical motions, engines and boilers, 1883, leaf 161
Fig. 208 (T. the order of procedure being shown in Figure 209.The Hnes for the full diameter of the thread being … Fiti. 209. drawn, the plu.li is stepped off by arcs, as i, 2,3, etr.;and from these, arcs, as 4, 5, 6, etc., arc marked forthe widlli of ih Hnt mI uv-s at the tops of tlie threads. SCREW THREADS AND SPIRALS. j^j Then one side of the thread Is marked off by lines, as7, which meet the arcs i, 2, 3,…

Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
