Mechanical drawing self-taught: comprising instructions in the selection and preparation of drawing instruments, elementary instruction in practical mechanical drawing together with examples in simple geometry and elementary mechanism, including screw threads, gear wheels, mechanical motions, engines and boilers (1883)

Rose, Joshua · Philadelphia, H.C. Baird & Co.; London, S. Low, Marston, Searle & Rivington · leaf 18

An illustration from Mechanical drawing self-taught: comprising instructions in the selection and preparation of drawing instruments, elementary instruction in practical mechanical drawing together with examples in simple geometry and elementary mechanism, including screw threads, gear wheels, mechanical motions, engines and boilers, 1883, leaf 18
sm; shaft for thecam plate; cross head ; side view and section through the centre of the eccentric and strap 301 Construction of the connecting rod 303 Index 305 Mechanical Drawing SEIjIP-TJ^TJa-XIT. CHAPTER I. THE DRAWING BOARD. A Drawing Board should be of soft pine and freefrom knots, so that it… … requisites in making a good drawing. Its edgesshould be straiQ:ht and at a ricrht ancrle one to theOther, and the ends of the battens B B in Figure i 2 (17) jg MECHANICAL DRAWING SELF-TAUGHT. should fall a little short of the edge A of the board, sothat if the latter shrinks they will not protrude.…

Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
