pyramid. Now connect the apex point withthe corners on the base and the figure is complete. To emphasize the convenience of these related axes, the student is reminded that measurements may De made only on isometriclines, and as the fines forming the outline of the pyramid base arenot at right… … Fig. 20. ical view of the side of the piece is divided into a certain numberof parts (any number), spaced either evenly or unevenly, thenthese lines or axes are used as shown when constructing the iso-metric view. Two applications are shown, one of which is pleasingto the eye, and the other quite…
