Leeds, Charles Carley, 1870- [from old catalog] · New York, D. Van Nostrand company · leaf 82
| inch larger in diameter at one end than at theother. By this time the student should be sufficiently familiar with handwheels to need no instruction on this subject. The binding screw shown is an illustration which shows the valueof a knowledge of shop practice. This screw is machined in a… … No 2 Morse Taper -gTap 8 R.H.Sq.Thd -// T 4r^.- 5|5 zf ixis Pin. Re a. 2
Mechanical drawing
