compass, by means of points in the arc, radius being given.—Suppose the radius is 20 feet and it is desired to obtain five points in anarc whose half chord is 4 feet. Draw a line equal to the half chord, fullsize, or on a smaller scale if more convenient, and erect a perpendicular atone end, thus… … GEOMETRICAL PROBLEMS. 53 x the values 0, 1, 2, 3, and 4, etc and for R2 the square of the radius, or400. The values will be y = V#» _ xi = V400, ^399, ^396, V39I, V384; = 20, 19.975, 19.90, 19.774, 19.596.Subtract the smallest, „„„„ „ * 4 or 19.596, leaving 0.404, 0.379, 0.304, 0.178, 0 feet. Lay…
