4), then, by the principleof the lever, find the reactions of the abutments Pi and R2. If P is theload applied at the point B on the lever CD, the fulcrum being D,then Bi X CD = P X BD and Ri X CD = P X BC; Ri = PX BD + CD;P2 = PX BC + CD. The strain on AC = Ri X AC -*> AS, and on AD = #2 X AD…
