hts of the H are the work-ing-parts of the valve, and the cross-bar between is madehollow and fits the exhaust-port, whose length is at rightangles to the length of the steam-ports (Fig. 148). VAL VE-GEARING. 191 lOi. Shortening the Throw of the Valve. Allen Valve. —Another expedient for… … Fig. 148. condition. If by keeping the throw of the eccentric largerthan the throw of the valve, there is yet opened an equalport-area with such reduced throw, there has been given tothe eccentric a mechanical advantage to overcome the pressurewhich holds the valve at its seat. Fig. 149 shows the…
