Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 329
ecylinder an inner lining which fits in properly preparedshoulders or flanges in the outer casing which forms thejacket. The joint between the lining and the rest of the cast-ing is made by copper rings. The cylinder-cover closes downupon this lining to prevent displacement. The other plan is,not… … LEAVITT JOINT. CORLISS JOI NT-. Fig. 234. Outside of the jacket, or protecting the cylinder-castingproper if there is no jacket, is a provision for some non-con-ducting material. This may be hair-felt, mineral wool, orwood, or combinations of these with asbestos board. Thisnon-conducting material…
Mechanical engineering · Steam power plants
