Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 401
these difficulties. This is done bywhat is called an exhaust-head. Fig.310 shows typical arrangements of suchan appliance. It is like a separator inprinciple. The water and oil strikingthe deflecting surfaces are caught bythem and drop downwards, and are car-ried away by the drip-pipe, while the… … FiG. 309. PIPING FOR THE ENGINE AND ITS ATTACHMENTS. 3^5 charge by perforated diaphragms, wire netting, layers of balls,and the like. HOBERTSOIV
Mechanical engineering · Steam power plants
