Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 438
he shank. (4) The shank should hammer cold to ? flat \ of an inchthick, and then withstand punching with a solid punch, makinga hole of the size of the original shank; both of these withoutcracking or splaying at the edges. THE STEAM-BOILER. GENERAL CONSTRUCTION. 4OI For wrought-iron rivets the… … Fig. 332. either ordinary or special. The ordinary riveted joints arefour: (i) Single-riveted lap. (2) Double-riveted lap. (3) Butt-joint with single cover. (4) Butt-joint with double cover. Figs. 332 to 338 illustrate these types. The lap-joint,,single- or double-riveted (Figs. 332 and 333), is…
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
