Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 450
n bars, single or independent sockets may beused as in Figs. 346 and 347, whereby the action of the staysis distributed even more generally over the surface to bestayed. Fig. 345 will serve for detail of these also. It isapparent that the diagonal stay must be stronger than the THE STEAM-BOILER.… … riveted by such flattened ends to head and to shell. Modernpractice does not favor these by reason of the uncertainty asto their holding capacity, and would limit them to very lowpressures or exclude them entirely. Gusset-stays are a form approved for heavy pressures inBritish practice. Triangular…
Mechanical engineering · Steam power plants
