Fig. 6. … Fig. 7 13. The Trunk-engine.—If the piston-rod of a typicalengine with the cross-head at its end be reduced to a pointy THE MECHANISM OE ENGINES. 21 while the connecting-rod is retained, the engine is shortenedby the length of two cranks and the stuffing-box allowances,and the pin upon which the…
