Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 618
FiG. 474. they will contain from condensation, whereas the form of Fig.473 will always hold the watc that had once entered it. Itis usual to secure the separation of hot steam from the gauge- … BOILER ACCESSORIES AND APPLIANCES. 581 spring by an intervening water-column, for which provision ismade by connecting the gauge to the boiler through a U tube,which will naake a siphon (Fig. 477). Fig. 475shows a device which produces the same effectas a water-seal. Provision, however, should…
Mechanical engineering · Steam power plants
