Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 122
Diameter of Cylinder. ...90 Length of Stroke of Piston 10 Number of Pumps g Dia. of Working Barrel 36 Auxiliary Barrel 5i Pump Stroke io Valves of the double-beatkind Double-acting Air Pump Diameter of Air Pump 3 3 Length of Stroke 5 g Height of centre of Beam aboveFig. 6o. level of Floor... 263…
Mechanical engineering · Steam power plants
