Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 346
CYLINDER, PISTON, AND PISTON-ROD. 29I soldered over the large opening, but not too strongly. Theplate is easily renewed if forced out by excess of water. 162. The Cylinder-jacket or Lagging.—The radiation ofheat from the cylinder must be reduced as far as possible.This is desirable, first, to… … Fig. 233. and it becomes desirable to diminish internal waste in thecylinder from re-evaporation of such condensed steam as faras possible. For this purpose the walls of the cylinder areoften cast hollow so that live steam from the boiler can circu-late through these hollow passages and keep the…
Mechanical engineering · Steam power plants
