Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 455
edshearing resistance as compared with a single row, and yet thesolid metal of the plate between holes can be increased withthe same pitch. The whole intent of special designs of rivetedjoint is to bring the plate strength between holes up to thepoint at which the joint shall be as strong as the… … Fig. 331. head made by hand, the bottom showing the usual pan-tailwhich the rivet has as manufactured. B is the cup or buttonhead resulting from the use of a swage. C or A will representforms given by the dies of riveting-machines. D is thecountersunk head usual in shipwork or where a smooth…
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
