Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 484
neck (Figs. 365 and 371;. TYPES OF BOILERS. 429 The flanges of the neck return some strength and stiffness tothe shell. It is more convenient, if this is to be done, tomake the dome a horizontal drum (Fig. 373). (3) To use a horizontal drum or pipe of large diameteroverhead, to which the boiler… … Fig. 365.this a drainage-connection may remove any entrained waterwhich may be carried through neck or nozzle by high velocityof steam-currents. Fig. 367 will .illustrate this arrangementwhen the drum is transverse, and is really a large pipe merelyjointed to each boiler by piping which allows of…
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
