Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 496
ues. The joint with the heads will be made by flanging theedges of a hole inward until the projecting flange will permitthe flue to be riveted to it, with the flue inside of the flange(Fig. 375). The flange might be turned outwards if the gaseswere never to be hot enough to overheat the projecting… … Flu. 376. The flue is exposed to the pressure in the boiler with atendency to be crushed inwards or collapsed by such pressure.A cylindrical flue of small diameter and homogeneous struc-ture ought to be strong to resist collapse, but a local over-heating combined with the effect of the weight of…
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
