Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 545
49° MECHANICAL ENGINEERING OF POWEK PLANTS. o( their class to a marked degree (par. 250). Besides theirrailroad use, they are used in high-speed torpedo-boats andover a wide field in stationary practice. 257. The Upright Boiler.—The locomotive-boiler typebecomes the upright type when the tubes are… … Fig. 417. type, and could almost be used in either position. The com-plicated staying of the crown-sheet disappears (Figs. 412 and430), and the fire-box and water-legs may conveniently now bemade cylindrical, and the barrel part become of the same sizeas the fire-box part, or nearly so. Fig. 418…
Mechanical engineering · Steam power plants
