Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 575
5^6 MECHANICAL ENGINEERING OF POWER PLANTS. Fig. 461 show typical constructions covering these pointsand methods. Fig. 433 illustrates a type of extended front which hasreceived some approval among the pure-water conditions in … Fig. 433,New England. The front of the furnace is a water-leg,through which the fire-door is made. It would be improvedby provisions to secure a determinate circulation of the water.Cleansing is effected bv the two blow-off pipes (par. 324). 268. The Dead-plate and Mouthpiece of the Furnace.—When…
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
