two other moving pieces. The crank-pin islubricated either by centrifugal force as shown in Fig. 506,whereby oil received near the centre of motion is carriedoutward through a pipe to the centre of the pin, and is theredistributed through a radial hole outwards upon the bearing-surface, or else a… … Fig. 505. wards upon the pin (Fig. 507). For the cross-head pin asimilar fixed cup is placed over the path of the cross-headhaving on its under side a piece of webbing or similar textilematerial upon which the oil drops and is spread. Illustrations 654 MECHANICAL ENGINEERING OF POWER PLANTS. of…
