Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 713
Fig. 505. wards upon the pin (Fig. 507). For the cross-head pin asimilar fixed cup is placed over the path of the cross-headhaving on its under side a piece of webbing or similar textilematerial upon which the oil drops and is spread. Illustrations 654 MECHANICAL ENGINEERING OF POWER PLANTS. of… … Fig. 506.
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
