^Perforations in Mixing Tube fordistributing Steam into the Water Extension of Mixing Tubesabove Water Level LeadingSteam in Regenerator fromManifold Water LevelBaffle Plate. Perforations in 1 luli-i Narrowed Portion \ Avy,of Mi King Tubes \ A^\\for Distributionof Steam in theWater Baffle Plate … Baffle Plato Fig. 44. Baffle PlateDrawings of Rateau Regenerator. orate, the heat required for evaporation being supplied by the heat liberated by the liquid inhaving its temperature lowered due to the drop in pressure. Example. Assuming that a closed vessel contains 1000 lb. water at a temperature…
